Motorized 2 position outdoor-air damper.

EconoMi$er X (for electro-mechanical controlled RTUs with CA Title 24 FDD).

EconoMi$er IV (for electro-mechanical controlled RTUs).

Smoke detector (supply and/or return air).

PremierLink DDC communicating controller.

Condenser coil hail guard (louvered design).

Humidi-MiZer Adaptive dehumidification system (sizes 04-28 only).

Thru-the-base electrical or gas-line connections.

3 years parts only on Novation™ condenser coil.

15 years parts only heat exchanger - stainless steel.

10 years parts only heat exchanger - aluminized.

Solid-state electronic direct spark ignition system and flame roll-out safety protector.

Exclusive IGC anti-cycle protection for gas heat operation.

Low pressure and high-pressure switch protection.

Totally enclosed condenser motors with permanently lubricated bearings.

Permanently lubricated evaporator-fan motor.24-volt control circuit protected with resettable circuit breaker.Scroll compressors with internal line-break overload protection.Full perimeter base rail with built-in rigging adapters and fork truck slots.Single point gas, electric, and controls connections.Dedicated vertical and horizontal airflow models available (sizes 17 to 30 only).Provisions for thru-the-bottom power entry capability as standard.Field convertible from vertical to horizontal airflow for slab mounting (sizes 04-16).Same footprint as installed Carrier 3-12.5 ton rooftops back to 1989, reducing installation costs and time.Belt drive evaporator-fan motor and pulley combinations available to meet any application.

Optional hinged access panels also available.

Innovative, easy starting, no-strip screw feature on unit access panels.

Control terminal board facilitating simple safety circuit troubleshooting and simplified control box arrangement.

Pre-painted exterior panels and primer-coated interior panels tested to 500 hours salt spray protection.

Exclusive IGC solid-state control for on-board diagnostics with LED error code designation, burner control logic and energy saving indoor fan motor delay.

Innovative non-corrosive composite condensate pan in accordance with ASHRAE 62 Standard, sloping design side or center drain.

Cooling operating range up to 115 ☏ (46☌) and down to 25☏ (-4☌) using winter start kit.
